Non Woven Fabric Flexo Label Printing Machine Water Based Ink

Brand Name : LS

Model Number : YTB

Certification : CE

Place of Origin : CHINA

MOQ : 1set

Supply Ability : 20set/month

Delivery Time : 30days before deposit

Packaging Details : wooden pallte

print color : 1. 2. 4 . 6 .8

print width : 600mm 800mm 1000mm

print speed : 80m/min

machine speed : 100m/min

Automatic Grade : Semi-Automatic

Printing Type : Flexo

Plate : Resin

Contact Now

Non Woven Fabric Flexo Label Printing Machine Water Based Ink

Usage:
This machine is suitable for printing such packing materials as PE plastic bag, glass paper and roll paper, etc. And it is a machine for printing T-shirt bag, shopping bag, vest bag and clothes bag, etc.

Characteristics:
1. Feature: Easy operation, flexible starting, accurate colour register.
2. Meter Counter: It is adopted to set printing quantity according to the needed production. The machine will stop automatically at the set quantity or when the material is cut off.
3. Printing plate: User can lift and lower the printing plate cylinder manually. It will automatically stir the printing ink after lifting.
4. Ink: The printing ink is spread by the knurled cylinder with even ink colour.
5. Drying system: Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6. Register: 360 degree continuous and adjustable longitudinal register device.
7. Frequancy inverter: The imported frequency control of motor speed adapts to different printing speeds.
8. Jogging device: There are jogging/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Main Technical Variables:
Model of Machine	YTB-4600	YTB-4800	YTB-41000
Max. Width of Printing Material	600mm	800mm	1000mm
Max. Printing Width	560mm	760mm	960mm
Length Range of Printed Product(mm)	191-914	191-914	191-914
Max. Diameter of Roll Material	Φ 450mm	Φ 450mm	Φ 450mm
Printing Speed	5-800m/min	5-800m/min	5-800m/min
Thickness of plate(Including Two-sided Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	19kw	25kw	30kw
Weight of Machine	3000kg	3500kg	4000kg
Overall(mm)Dimensions	4200X1600X2400	4200X1800X2400	4200X2000X2400
